| - 各弯曲应力别 试品长度 - | ||||||
| 单位(㎜) | ||||||
| 单丝径 | Setting Bending Stress(Kg) | |||||
| (mm) | 150 | 140 | 130 | 120 | 110 | |
| 0.150 | 夹具-轴套间距 | 25.26 | 27.06 | 29.15 | 31.58 | 34.45 |
| 试品长度 | 55.32 | 59.27 | 63.83 | 69.15 | 75.44 | |
| 所需试品总长度 | 87.32 | 91.27 | 95.83 | 101.15 | 107.44 | |
| 0.175 | 夹具-轴套间距 | 29.48 | 31.59 | 34.02 | 36.85 | 40.20 |
| 试品长度 | 64.56 | 69.17 | 74.49 | 80.70 | 88.04 | |
| 所需试品总长度 | 96.56 | 101.17 | 106.49 | 112.70 | 120.04 | |
| 0.200 | 夹具-轴套间距 | 33.69 | 36.10 | 38.89 | 42.11 | 45.94 |
| 试品长度 | 73.78 | 79.05 | 85.13 | 92.23 | 100.60 | |
| 所需试品总长度 | 105.78 | 111.05 | 117.13 | 124.23 | 132.60 | |
| 0.220 | 夹具-轴套间距 | 37.06 | 39.71 | 42.76 | 46.33 | 50.54 |
| 试品长度 | 81.16 | 86.96 | 93.65 | 101.45 | 110.67 | |
| 所需试品总长度 | 113.16 | 118.96 | 125.65 | 133.45 | 142.67 | |
| 0.250 | 夹具-轴套间距 | 42.11 | 45.12 | 48.59 | 52.64 | 57.42 |
| 试品长度 | 92.22 | 98.81 | 106.41 | 115.28 | 125.75 | |
| 所需试品总长度 | 124.22 | 130.81 | 138.41 | 147.28 | 157.75 | |
| 0.280 | 夹具-轴套间距 | 47.17 | 50.54 | 54.43 | 58.96 | 64.32 |
| 试品长度 | 103.30 | 110.68 | 119.19 | 129.13 | 140.86 | |
| 所需试品总长度 | 135.30 | 142.68 | 151.19 | 161.13 | 172.86 | |
| 0.300 | 夹具-轴套间距 | 50.54 | 54.15 | 58.32 | 63.18 | 68.92 |
| 试品长度 | 110.68 | 118.59 | 127.72 | 138.36 | 150.93 | |
| 所需试品总长度 | 142.68 | 150.59 | 159.72 | 170.36 | 182.93 | |
| 0.320 | 夹具-轴套间距 | 53.91 | 57.76 | 62.20 | 67.39 | 73.51 |
| 试品长度 | 118.06 | 126.49 | 136.22 | 147.58 | 160.99 | |
| 所需试品总长度 | 150.06 | 158.49 | 168.22 | 179.58 | 192.99 | |
| 0.350 | 夹具-轴套间距 | 58.96 | 63.17 | 68.03 | 73.70 | 80.40 |
| 试品长度 | 129.12 | 138.34 | 148.99 | 161.40 | 176.08 | |
| 所需试品总长度 | 161.12 | 170.34 | 180.99 | 193.40 | 208.08 | |
| 0.380 | 夹具-轴套间距 | 64.01 | 68.58 | 73.86 | 80.01 | 87.29 |
| 试品长度 | 140.18 | 150.19 | 161.75 | 175.22 | 191.17 | |
| 所需试品总长度 | 172.18 | 182.19 | 193.75 | 207.22 | 223.17 | |
| 0.600 | 夹具-轴套间距 | 101.07 | 108.29 | 116.62 | 126.34 | 137.82 |
| 试品长度 | 211.34 | 237.16 | 255.40 | 276.68 | 301.83 | |
| 所需试品总长度 | 243.34 | 269.16 | 287.40 | 308.68 | 333.83 | |
| 0.710 | 夹具-轴套间距 | 119.61 | 128.16 | 138.02 | 149.53 | 163.12 |
| 试品长度 | 261.95 | 280.67 | 302.26 | 327.47 | 357.23 | |
| 所需试品总长度 | 293.95 | 312.67 | 334.26 | 359.47 | 389.23 | |
